Acura RL II (2004-2008) lf lf gnd rf lf gnd lr lf gnd rr lf gnd pnk Wiring diagram
This page shows the only wiring diagram for the component.lf lf gnd rf lf gnd lr lf gnd rr lf gnd pnk, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf lf gnd rf lf gnd lr lf gnd rr lf gnd pnk (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 B+
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 12
FUSE 21
FUSE 7
GAUGE CONTROL
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
K-LINE CANL
LEFT FRONT TPMS INITIATOR (BEHIND LEFT SIDE OF FRONT BUMPER)
LEFT REAR TPMS INITIATOR (ON LEFT REAR FENDERWELL)
LF LF GND RF LF GND LR LF GND RR LF GND PNK WIRE
LF LF PWR RF LF PWR LR LF PWR RR LF PWR
LOW TIRE PRESSURE INDICATOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
TPMS INDICATOR
TPMS RECEIVER UNIT (RIGHT SIDE OF REAR SHELF)
WARNING DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit (1 of 2) -> LF LF GND RF LF GND LR LF GND RR LF GND PNK WIRE
