Acura RL II (2004-2008) left turn signal indicator right turn signal indicator Wiring diagrams
This page contains all the electrical diagrams for the component. left turn signal indicator right turn signal indicator, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left turn signal indicator right turn signal indicator (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S UNDER-DASH FUSE/RELAY BOX
FROM DRIVER'S UNDER-DASH
FUSE/RELAY BOX
GAUGE CONTROL MODULE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
LEFT BRAKE LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT LEFT SIDE MARKER LIGHT
LEFT TURN SIGNAL INDICATOR RIGHT TURN SIGNAL INDICATOR
LT GRN WIRE
MICU
RED/BLK WIRE
RIGHT BRAKE LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE MARKER LIGHT
RIGHT TAILLIGHT
TURN SIGNAL/ HAZARD RELAY 1
TURN SIGNAL/ HAZARD RELAY 2
TURN SW L PG
TURN SW R
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, without technology package (2 of 3) -> LEFT TURN SIGNAL INDICATOR RIGHT TURN SIGNAL INDICATOR
