Acura RL II (2004-2008) knob lock solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. knob lock solenoid, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram knob lock solenoid (1 of 2)
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
EXT F - EXT F + EXT FR AS + RXVCC TXVCC RSSI
EXT FR AS - RFRXD RFTXD
EXT FR DR - EXT FR DR + EXT TR - EXT TR + RSSI RFRXD RFTXD
FRONT INTERIOR LF ANTENNA (BEHIND MIDDLE OF DASH)
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IGNITION SWITCH CONTROL UNIT
KEY SW HBRK SW KEY OUT IMMOCONT
KEYLESS ACCESS CONTROL UNIT (UNDER LEFT SIDE OF DASH)
KEYLESS ACCESS RF UNIT 2 (MIDDLE OF REAR SHELF)
KNOB LOCK SOLENOID
KNOB SWITCH
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
OTR HNDL EXT R - EXT R + EXT TI - EXT TI +
PNK PNK WIRE
PNK WIRE
PPL
REAR BUMPER LF ANTENNA (BEHIND MIDDLE OF REAR BUMPER)
REAR INTERIOR LF ANTENNA (UNDER REAR OF CENTER CONSOLE)
REAR SHELF LF ANTENNA (MIDDLE OF REAR SHELF)
RED WIRE
RF GND
RF GND RXVCC TXVCC
ROTATE SW KNOB SW IMMOBI ALRM DIAG H S NET IGN TRX
ROTATE SWITCH
SCS IGN CNTRL
SMART MIL
TS FR AS DL FR AS
TS FR DR DL FR DR
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (5 of 5) -> KNOB LOCK SOLENOID
