Acura RL II (2004-2008) high mount brake light Wiring diagrams
This page contains all the electrical diagrams for the component. high mount brake light, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high mount brake light (1 of 3)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BRAKE PEDAL POSITION SWITCH 1) PEDAL
BRN WIRE
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
DRIVER'S UNDER-DASH
FUSE 21
FUSE 7
FUSE/RELAY BOX
GRN WIRE
GRY WIRE
HAZARD SW
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH LIGHT
HEADLIGHT SWITCH 0) OFF 1) PARK 2) HEAD
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MICU
PCM (UNDER MIDDLE OF DASH)
PNK WIRE
PRESSED (NEAR BRAKE PEDAL)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SG-1 B-CAN
STOP SW
TO DRIVER'S UNDER-DASH
TURN SIGNAL LIGHT SWITCH
VBU
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Exterior lamps circuit, without technology package (1 of 3) -> HIGH MOUNT BRAKE LIGHT
Wiring diagram high mount brake light (2 of 3)
ADAPTIVE CRUISE CONTROL RELAY
AUXILIARY UNDER-HOOD RELAY BOX (LEFT REAR OF ENGINE COMPT)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH 1) PEDAL
BRN WIRE
COMBINATION LIGHT SWITCH
COMBINATION SWITCH CONTROL UNIT
CONTROL UNIT (BEHIND RIGHT SIDE OF GLOVE BOX)
DRIVER'S UNDER-DASH
FUSE 21
FUSE 29
FUSE 7
FUSE/RELAY BOX
GRN WIRE
GRY WIRE
HAZARD SW
HAZARD WARNING SWITCH
HEADLIGHT SWITCH 0) OFF 1) PARK 2) HEAD
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
MICU
ORG/ WIRE
PCM (UNDER MIDDLE OF DASH)
PNK WIRE
PRESSED (NEAR BRAKE PEDAL)
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SG-1 B-CAN
STOP SW
TO DRIVER'S UNDER-DASH
TURN SIGNAL LIGHT SWITCH
VBU
WHT WIRE
WHT/BLK WIRE
WIPER/ WASHER SWITCH
YEL WIRE
Go to component -> Exterior lamps circuit, with technology package (1 of 3) -> HIGH MOUNT BRAKE LIGHT
Wiring diagram high mount brake light (3 of 3)
ACCESSORY POWER SOCKET RELAY
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
DRIVER'S DOOR OUTER HANDLE LIGHT/ TOUCH SENSOR
DRIVER'S LUMBAR SUPPORT SWITCH
DRIVER'S MPCS UNIT
DRIVER'S SEAT BACK FAN MOTOR (CANADA)
DRIVER'S SEAT BELT SWITCH
DRIVER'S SEAT CUSHION FRONT FAN MOTOR (CANADA)
DRIVER'S SEAT CUSHION REAR FAN MOTOR (CANADA)
DRIVER'S SEAT HEATER (USA)
DRIVER'S SEAT VENTILATION CONTROL UNIT (CANADA)
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND RIGHT KICK PANEL)
DRIVER'S VANITY MIRROR LIGHT
DRIVING POSITION MEMORY SWITCH
E-TENSIONER UNIT (TECHNOLOGY PACKAGE)
FRONT PASSENGER'S VANITY MIRROR LIGHT
HIGH MOUNT BRAKE LIGHT
J/C
KEYLESS ANSWER BACK BUZZER
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT POWER MIRROR
LEFT REAR ASHTRAY LIGHT
LEFT REAR POWER WINDOW SWITCH
MICU
MICU SERVICE CHECK CONNECTOR
MOONROOF CONTROL UNIT
PG SG-2
POWER SEAT CONTROL UNIT
PPL
REAR INDIVIDUAL MAP LIGHTS
REAR WINDOW DEFOGGER
RED WIRE
RIGHT ACURALINK CONTROL UNIT (XM RECEIVER) (USA) BRAKE LIGHT/ TAILLIGHT
ROOF CONSOLE
TRUNK LID LATCH SWITCH
TRUNK LID OPENER/ FUEL LID OPENER SWITCH
TURN SIGNAL/ HAZARD RELAY 1
WHT WIRE
Go to component -> Ground distribution circuit (3 of 4) -> HIGH MOUNT BRAKE LIGHT
