Acura RL II (2004-2008) fog lights ind Wiring diagram
This page shows the only wiring diagram for the component.fog lights ind, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fog lights ind (1 of 1)
A/T GEAR POSITION IND ILLUMINATION CONTROL, DIMMING CIRCUIT
ABS IND.
AFS IND
ANTI-THEFT SYSTEM
ANTI-THEFT SYSTEM EXTERIOR LIGHTS SYSTEM ANTI-LOCK BRAKES SYSTEM
BEEPER
BLK WIRE
BLU WIRE
BODY CONTROLLER AREA NETWORK TRANSCEIVER
BRAKE SYSTEM IND
BRN WIRE
CHARGING SYSTEM IND
COMPULSORY TURNING- OFF CIRCUIT
COMPULSORY TURNING- ON CIRCUIT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL DIMMING CIRCUIT
CRUISE CONTROL MAIN SWITCH IND
CRUISE CONTROL SYSTEM
CRUISE CONTROL SYSTEM ABS SYSTEM (W/ TECH PACKAGE)
DIAL/SHIFT IND ILLUMINATION, DIMMING CIRCUIT
DRIVE CIRCUIT
ECPS IND
ELECTRONIC POWER STEERING SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE
FAIL SAFE CIRCUIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FOG LIGHTS IND
FUEL GAUGE
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH BEAM IND
IMMOBILIZER SYSTEM IND
INFORMATION IND
INTERIOR LIGHTS SYSTEMS
KEYLESS ACCESS SYSTEM IND
LCD BACK LIGHT
LCD/POINTER ILLUMINATION CONTROL, DIMMING CIRCUIT
LED LIGHT
LEFT TURN SIGNAL IND
LIGHTS ON IND
LIGHTS ON/FOG LIGHT BRIGHTNESS CONTROL, DIMMING CIRCUIT
LOW FUEL IND
LOW OIL PRESSURE IND
LOW TIRE PRESSURE IND
LT BLU WIRE
LT GRN WIRE
MIL IND
MULTI INFORMATION DISPLAY (MID) UNIT
ORG/ WIRE
PNK 1 2 WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
RIGHT TURN SIGNAL IND
SEAT BELT REMINDER IND
SECURITY IND
SECURITY IND BLINKING CIRCUIT
SH-AWD IND
SIDE AIRBAG CUT-OFF IND
SPEEDO- METER
SRS IND
SRS IND CIRCUIT
SUPPLEMENTAL RESTRAINTS SYSTEM
TACHOMETER
VSA ACTIVATION IND
VSA SYSTEM IND
WARNING DRIVE CIRCUIT
WHT WIRE
WIPER/WASHER SYSTEM EXTERIOR LIGHTS SYSTEM
Go to component -> Instrument cluster circuit (1 of 2) -> FOG LIGHTS IND
