Acura RL II (2004-2008) bus shld Wiring diagrams
This page contains all the electrical diagrams for the component. bus shld, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram bus shld (1 of 2)
1 2 3 PPL PPL
AM SIGNAL WINDOW ANTENNA
AUDIO UNIT
BUS (-) BUS (+)
BUS SHLD
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FM SIGNAL SUB-WINDOW ANTENNA
FM SIGNAL WINDOW ANTENNA
FUSE 32
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INTERFACE DIAL
J/C
LT GRN WIRE
MAIN ANTENNA MODULE (IN RIGHT "C" PILLAR)
NCA WIRE
NEP
PCM (UNDER MIDDLE OF DASH)
PPL
PPL 12 13
PPL PPL
PPL/ PPL/ PPL/
REAR WINDOW
RED WIRE
SUB- ANTENNA MODULE (IN LEFT "C" PILLAR)
WHT WIRE
Go to component -> Radio circuit, canada (4 of 5) -> BUS SHLD
Wiring diagram bus shld (2 of 2)
1 2 3 PPL PPL
ACURALINK CONNECTOR
ACURALINK CONTROL UNIT (XM RECEIVER) (LEFT SIDE OF TRUNK)
AM SIGNAL WINDOW ANTENNA
AUDIO UNIT
BLK WIRE
BUS (-) BUS (+)
BUS -
BUS SHLD
BUS SHLD HP SHLD HP R + HP L +
CAN HI
CAN LO
COMPUTER DATA LINES SYSTEM
DIAG LINE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FM SIGNAL SUB-WINDOW ANTENNA
FM SIGNAL WINDOW ANTENNA
FUSE 32
GRN WIRE
GRY WIRE
HFT COM 1
HFT COM 2
HFT COM 3
HFT COM 4
HFT COM SHLD
HOT AT ALL TIMES
HP L
HP MUTE
HP R
HP R - HP L -
HP SHLD
INTERFACE DIAL
J/C
LINE OUT +
LINE OUT SHLD
LT GRN WIRE
MAIN ANTENNA MODULE (IN RIGHT "C" PILLAR)
MICU +B
NCA WIRE
NEP
ORG/ WIRE
PCM (UNDER MIDDLE OF DASH)
PPL
PPL 19 20
PPL PPL
PPL/ PPL/ PPL/
REAR WINDOW
RED WIRE
RX-
SATELLITE SIGNAL ANTENNA
SATELLITE SIGNAL ANTENNA MODULE
SHLD
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
SUB- ANTENNA MODULE (IN LEFT "C" PILLAR)
TERRESTRIAL SIGNAL ANTENNA
TERRESTRIAL SIGNAL ANTENNA MODULE
TX(-)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, usa (4 of 5) -> BUS SHLD
