Acura RL II (2004-2008) blower glove power box light transistor Wiring diagram
This page shows the only wiring diagram for the component.blower glove power box light transistor, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram blower glove power box light transistor (1 of 1)
ADAPTIVE FRONT LIGHTING CONTROL
AFS OFF/ VSA OFF/ CMBS OFF/ SWITCH
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BLOWER GLOVE POWER BOX LIGHT TRANSISTOR
BLU WIRE
BRAKE FLUID LEVEL SWITCH
CABLE REEL
CONSOLE LIGHT
CONTROL UNIT (TECHNOLOGY PACKAGE)
CONTROL UNIT)
DASH CLIMATE LIGHTS CONTROL BRIGHTNESS CONTROLLER UNIT
DATA LINK CONNECTOR
DRIVER'S SEAT HEATER SWITCH
DRIVER'S UNDER-DASH
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
DRL CONTROL UNIT (USA)
ECPS CONTROL UNIT
FRONT ACCESSORY POWER SOCKET
FRONT COIN PASSENGER'S POCKET LIGHT SEAT HEATER
FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FUSE/RELAY HEADLIGHT BOX WASHER (BEHIND RIGHT RELAY KICK PANEL)
GAUGE CONTROL MODULE
IGNITION SWITCH CONTROL UNIT
IN-CAR TURN TEMPERATURE SIGNAL/ SENSOR HAZARD RELAY 2
INTERFACE DIAL
J/C
KEYLESS ACCESS CONTROL UNIT
KNOB SWITCH/ DOOR SWITCH
LIGHT/ TOUCH SENSOR
LOCK ACTUATOR
MES CONNECTOR
MICU
MILLIMETER WAVE RADAR (TECHNOLOGY PACKAGE)
MILLIMETER WAVE RADAR SHIELD (TECHNOLOGY PACKAGE)
OUTER HANDLE
PARK PIN SWITCH
PASSENGER'S UNDER-DASH
POWER MIRROR SWITCH
POWER TILT/ TELESCOPIC STEERING
PPL
RADIATOR FAN CONTROL UNIT
REAR ACCESSORY POWER SOCKET
RIGHT POWER MIRROR
SEAT FUEL HEATER FILL RELAY DOOR OPENER RELAY
SECURITY HOOD SWITCH
SOUNDER-
SRS UNIT
SWITCH (USA:
TRANSMISSION GEAR SELECTION SWITCH
TRUNK LID OPENER MAIN SWITCH
UNIT)
USA
WHT WIRE
WIND- SHIELD WIPER MOTOR
WIPER/ WASHER SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> BLOWER GLOVE POWER BOX LIGHT TRANSISTOR
