Acura RL II (2004-2008) auxiliary under hood relay box Wiring diagram
This page shows the only wiring diagram for the component.auxiliary under hood relay box, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auxiliary under hood relay box (1 of 1)
AUXILIARY UNDER HOOD RELAY BOX
BLK WIRE
BUMPER)
CONTROL BLOCK
DRL RELAY
FOG LIGHT RELAY
FUSE 11
FUSE 5 FUSE 3
FUSE 6 FUSE 1
GRN WIRE
HID UNIT HIGH BEAM
HIGH BEAM HEADLIGHT RELAY
HOT AT ALL TIMES
LEFT FOG LIGHT
LEFT HEADLIGHT
LOW BEAM
LOW BEAM HEADLIGHT RELAY
LT BLU WIRE
LT GRN WIRE
PPL
RED WIRE
RIGHT FOG LIGHT
RIGHT HEADLIGHT
UNDER-HOOD FUSE/RELAY BOX RELAY CONTROL MODULE
WHT WIRE
YEL WIRE
Go to component -> Headlamps & fog lamps circuit, canada (2 of 2) -> AUXILIARY UNDER HOOD RELAY BOX
