Acura RL II (2004-2008) a/t gear position ind drive circuit Wiring diagrams
This page contains all the electrical diagrams for the component. a/t gear position ind drive circuit, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/t gear position ind drive circuit (1 of 2)
22 23 24 25 PPL
A/T GEAR IND/CRUISE CONTROL DIMMING CIRCUIT
A/T GEAR POSITION DETECTION CIRCUIT
A/T GEAR POSITION IND DRIVE CIRCUIT
A/T GEAR POSITION INDICATOR BRIGHTNESS CONTROL, DIMMING CIRCUIT
ATPP
ATPR
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FAST CONTROLLER AREA NETWORK TRANSCEIVER
GAUGE CONTROL MODULE
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
LCD BACK LIGHT
LED LIGHT
LT BLU WIRE
LT GRN WIRE
MICU
MIL IND
ORG/ WIRE
P-PIN
PNK WIRE
POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
PPL
PPL 19 20
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
SHIFT INDICATOR BRIGHTNESS CONTROL AND DIMMING CIRCUIT
STARTING/ CHARGING SYSTEM
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Transmission circuit (2 of 3) -> A/T GEAR POSITION IND DRIVE CIRCUIT
Wiring diagram a/t gear position ind drive circuit (2 of 2)
