Acura RL II (2004-2008) alt fr sig alt alt Wiring diagram
This page shows the only wiring diagram for the component.alt fr sig alt alt, which is found in the car Acura RL II (2004-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram alt fr sig alt alt (1 of 1)
ALT FR SIG ALT ALT
ALTERNATOR IG
BATTERY
BLK WIRE
BLU WIRE
CHARGING SYSTEM INDICATOR
COMM SIG LOW
DRIVE CIRCUIT
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
ELD IN- PUT COMM SIG HIGH
ELD UNIT
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 18
FUSE 21
GAUGE CONTROL MODULE
GRN WIRE
GROUND
HOT IN ON OR START
IGNITION INPUT
J/C
LOAD OUTPUT
MULTI- FUSE 22
ORG/ WIRE
PCM (UNDER MIDDLE OF DASH)
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
SIG SIG
STARTING CIRCUIT
UNDER HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> ALT FR SIG ALT ALT
