Acura RL II (2004-2008) acuralink connector Wiring diagrams
This page contains all the electrical diagrams for the component. acuralink connector, in which he is found in the car Acura RL II (2004-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram acuralink connector (1 of 2)
ACTIVE NOISE CONTROL UNIT
ACURALINK CONNECTOR
ACURALINK CONTROL UNIT (XM RECEIVER)
AUDIO AMPLIFIER
BLK WIRE
DISPLAY PANEL CONTROL UNIT
FRONT ACTIVE NOISE CONTROL MICROPHONE
FRONT PASSENGER'S LUMBAR SUPPORT SWITCH
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT BACK FAN MOTOR (CANADA)
FRONT PASSENGER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT HEATER (USA)
FRONT PASSENGER'S SEAT VENTILATION CONTROL UNIT (CANADA)
FUEL FILL DOOR OPENER SOLENOID
FUEL PUMP CONTROL MODULE
HANDS FREE LINK CONTROL UNIT
J/C
LEFT "C" PILLAR)
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
LEFT REAR HEADREST ACTUATOR
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SWITCH
NAVIGATION UNIT
NOISE REDUCTION CONDENSER
ONSTAR CONTROL UNIT
OPDS UNIT
POWER REAR WINDOW SUNSHADE CONTROL UNIT
REAR ACTIVE NOISE CONTROL MICROPHONE
RIGHT CENTER HEADREST ACTUATOR
RIGHT REAR DOOR ASHTRAY LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH/ DOOR SWITCH
RIGHT REAR HEADREST ACTUATOR
RIGHT REAR POWER WINDOW MOTOR
RIGHT REAR POWER WINDOW SWITCH
SEAT WEIGHT SENSOR UNIT
SH-AWD SH-AWD CONTROL RELAY UNIT
TPMS RECEIVER UNIT WINDOW MOTOR
TRUNK LEFT RIGHT LID OUTER HANDLE SWITCH LICENSE PLATE LIGHT LICENSE PLATE LIGHT
Go to component -> Ground distribution circuit (4 of 4) -> ACURALINK CONNECTOR
Wiring diagram acuralink connector (2 of 2)
1 2 3 PPL PPL
ACURALINK CONNECTOR
ACURALINK CONTROL UNIT (XM RECEIVER) (LEFT SIDE OF TRUNK)
AM SIGNAL WINDOW ANTENNA
AUDIO UNIT
BLK WIRE
BUS (-) BUS (+)
BUS -
BUS SHLD
BUS SHLD HP SHLD HP R + HP L +
CAN HI
CAN LO
COMPUTER DATA LINES SYSTEM
DIAG LINE
DRIVER'S UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
FM SIGNAL SUB-WINDOW ANTENNA
FM SIGNAL WINDOW ANTENNA
FUSE 32
GRN WIRE
GRY WIRE
HFT COM 1
HFT COM 2
HFT COM 3
HFT COM 4
HFT COM SHLD
HOT AT ALL TIMES
HP L
HP MUTE
HP R
HP R - HP L -
HP SHLD
INTERFACE DIAL
J/C
LINE OUT +
LINE OUT SHLD
LT GRN WIRE
MAIN ANTENNA MODULE (IN RIGHT "C" PILLAR)
MICU +B
NCA WIRE
NEP
ORG/ WIRE
PCM (UNDER MIDDLE OF DASH)
PPL
PPL 19 20
PPL PPL
PPL/ PPL/ PPL/
REAR WINDOW
RED WIRE
RX-
SATELLITE SIGNAL ANTENNA
SATELLITE SIGNAL ANTENNA MODULE
SHLD
SRS UNIT (UNDER LOWER MIDDLE OF DASH)
SUB- ANTENNA MODULE (IN LEFT "C" PILLAR)
TERRESTRIAL SIGNAL ANTENNA
TERRESTRIAL SIGNAL ANTENNA MODULE
TX(-)
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, usa (4 of 5) -> ACURALINK CONNECTOR
