Car Wiring Diagrams for Seat ventilation circuit for Acura RDX III (2018-2021)

BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL PANEL CLIMATE CONTROL UNIT COMPUTER DATA LINES SYSTEM DRIVER'S SEAT CUSHION BLOWER MOTOR DRIVER'S SEAT CUSHION HEATER DRIVER'S SEAT HEATER SWITCH DRIVER'S SEAT HEATER SWITCH IND DRIVER'S SEAT- BACK HEATER DRIVER'S SEAT-BACK BLOWER MOTOR DRIVER'S VENTILATED SEAT SWITCH DRIVER'S VENTILATED SEAT SWITCH IND FRONT PASSENGER'S SEAT BACK HEATER FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR FRONT PASSENGER'S SEAT CUSHION HEATER FRONT PASSENGER'S SEAT HEATER SWITCH FRONT PASSENGER'S SEAT HEATER SWITCH IND FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR FRONT PASSENGER'S VENTILATED SEAT SWITCH FRONT PASSENGER'S VENTILATED SEAT SWITCH IND FUSE 15 FUSE 5 FUSE EC FUSE/RELAY HOLDER GRN WIRE HOT AT ALL TIMES HOT W/ DC-DC LT BLU WIRE MOTOR DRIVE IC PNK WIRE POWER DISTRIBUTION MODULE PPL RED WIRE RELAY 2 ENERGIZED SMART FET TAN WIRE UNDER-HOOD FUSE/RELAY BOX VENTILATED SEAT CONTROL UNIT WHT WIRE YEL WIRE
