Acura RDX III (2018-2021) Memory mirrors circuit
Memory mirrors circuit (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S JUNCTION BOX B
DRIVER'S POWER SEAT CONTROL UNIT
DRIVING POSITION MEMORY SWITCH
FUSE 1
FUSE 36
FUSE 39
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR 1 (LED)
INDICATOR 2 (LED)
LEFT
LIGHTS (LED)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POSITION 1 SWITCH
POSITION 2 SWITCH
POWER MIRROR CONTROL UNIT
POWER MIRROR SWITCH
PPL
RED WIRE
RELAY ENERGIZED
RETRACT SWITCH
RIGHT
SET SWITCH
SWITCH 1
SWITCH 2
SWITCH 3
TAN WIRE
THERMAL JOINT 11
THERMAL JOINT 5
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Memory mirrors circuit (2 of 2)
AUTO TURN UNIT
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DEFOGGER
DEFOGGER SYSTEM
DOOR MULTIPLEX CONTROL UNIT
FRONT PASSENGER'S POWER WINDOW SWITCH
GRN WIRE
GRY WIRE
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT
LT BLU WIRE
LT GRN WIRE
MIRROR ACTUATOR
NAVIGATION SYSTEM
NCA WIRE
PNK WIRE
POSITION SENSOR
POWER WINDOW MASTER SWITCH
PPL
RED WIRE
RETRACT ACTUATOR
RIGHT POWER MIRROR
RIGHT SIDE TURN SIGNAL LIGHT
SWING (HORIZONTAL)
TAN WIRE
THERMAL JOINT 11
TILT (VERTICAL)
WHT WIRE
YEL WIRE
