Acura RDX III (2018-2021) sh-awd relay relay holder a Wiring diagram
This page shows the only wiring diagram for the component.sh-awd relay relay holder a, which is found in the car Acura RDX III (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sh-awd relay relay holder a (1 of 1)
12 VOLT BATTERY FAN MOTOR
ADAPTIVE FRONT LIGHTING CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CAN GATEWAY
CENTER DISPLAY UNIT
COMPUTER DATA LINES SYSTEM
DIODE A
DRIVER'S POWER SEAT CONTROL UNIT
ELECTRIC BRAKE BOOSTER
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FUSE 1
FUSE 15
FUSE 2
FUSE 28
FUSE 3
INTEGRATED DYNAMICS SYSTEM SWITCH
LT GRN WIRE
PARKING, BACKUP SENSOR CONTROL UNIT
PARKING, BACKUP SENSOR SWITCH/ VSA OFF SWITCH
POWER MIRROR CONTROL UNIT
POWER TAILGATE CONTROL UNIT
PPL
REAR DIFFERENTIAL PUMP MOTOR
RED WIRE
REVERSE RELAY
RIGHT END OF DASH)
SH-AWD CONTROL UNIT
SH-AWD RELAY RELAY HOLDER A
STARTER CUT RELAY 1
STARTER CUT RELAY 2
THERMAL JOINT 5
TO FUSE/RELAY HOLDER (DIAGRAM 7 OF 9)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
Go to component -> Power distribution circuit (9 of 9) -> SH-AWD RELAY RELAY HOLDER A
