Acura RDX III (2018-2021) sh-awd relay Wiring diagrams
This page contains all the electrical diagrams for the component. sh-awd relay, in which he is found in the car Acura RDX III (2018-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
sh-awd relay wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 3
FUSE 4
FUSE HOLDER A
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/
LEFT REAR DIFFERENTIAL FLUID PRESSURE SENSOR
LEFT REAR DIFFERENTIAL SOLENOID VALVE
LT BLU WIRE
PNK WIRE
REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR
REAR DIFFERENTIAL HOUSING
REAR DIFFERENTIAL PUMP MOTOR
RED WIRE
RIGHT REAR DIFFERENTIAL FLUID PRESSURE SENSOR
RIGHT REAR DIFFERENTIAL SOLENOID VALVE
SH-AWD CONTROL UNIT
SH-AWD RELAY
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Awd circuit -> SH-AWD RELAY
sh-awd relay wiring diagram (2 of 2)
BLU WIRE
BRN WIRE
DRIVER'S POWER SEAT CONTROL UNIT
ELECTRIC BRAKE BOOSTER
FROM FUSE 1-4 (DIAGRAM 1 OF 9)
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FUSE 1-2
FUSE 1-3
FUSE 1-5
FUSE 1-6
FUSE 10
FUSE 11
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 24
FUSE 4
FUSE 7
FUSE 8
FUSE 9
FUSE HOLDER A
GRN WIRE
HEADLIGHT WASHER RELAY RELAY HOLDER C
LT BLU WIRE
LT GRN WIRE
OPTION CONNECTOR (FOR TRAILER)
PNK WIRE
POWER SUNSHADE MOTOR- CONTROL UNIT
POWER TAILGATE CONTROL UNIT
PPL
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY HOLDER A
SBW SHIFTER CONTROL MODULE
SH-AWD CONTROL UNIT
SH-AWD RELAY
STEREO AMPLIFIER
TO FUSE 1-7 (DIAGRAM 7 OF 9)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 4 OF 9)
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
WHT WIRE
WINDSHIELD WIPER CONTROL UNIT/MOTOR
YEL WIRE
Go to component -> Power distribution circuit (3 of 9) -> SH-AWD RELAY
