Acura RDX III (2018-2021) right rear door outer handle Wiring diagrams
This page contains all the electrical diagrams for the component. right rear door outer handle, in which he is found in the car Acura RDX III (2018-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right rear door outer handle wiring diagram (1 of 3)
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCK KNOB
FUSE 18
FUSE 25
FUSE 39
GAUGE CONTROL MODULE
GRN WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
LOCK
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR DOOR OUTER HANDLE
RIGHT REAR DOOR SWITCH
SECURITY INDICATOR
TAN WIRE
THERMAL JOINT 4
TOUCH SENSOR (LOCK)
TOUCH SENSOR (UNLOCK)
UNDER- HOOD FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
UNLOCK
W/ KEYLESS ACCESS
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (4 of 6) -> RIGHT REAR DOOR OUTER HANDLE
right rear door outer handle wiring diagram (2 of 3)
A/C CONDENSER FAN MOTOR
ADAPTIVE DAMPER CONTROL UNIT
BLK WIRE
BRN WIRE
FRONT PASSENGER'S POWER SEAT CONTROL UNIT
FRONT PASSENGER'S SEAT BACK HEATER
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT CUSHION BLOWER MOTOR
FRONT PASSENGER'S SEAT CUSHION HEATER
FRONT PASSENGER'S SEAT HEIGHT MOTOR
FRONT PASSENGER'S SEAT HEIGHT SUPPORT MOTOR
FRONT PASSENGER'S SEAT LEFT BOLSTER MOTOR
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR A
FRONT PASSENGER'S SEAT POWER LUMBAR SUPPORT MOTOR B
FRONT PASSENGER'S SEAT RECLINE MOTOR
FRONT PASSENGER'S SEAT RIGHT BOLSTER MOTOR
FRONT PASSENGER'S SEAT SLIDE MOTOR
FRONT PASSENGER'S SEAT TILT MOTOR
FRONT PASSENGER'S SEAT-BACK BLOWER MOTOR
FUEL TANK UNIT
HANDSFREE ACCESS POWER TAILGATE CONTROL UNIT/ SENSOR
KEYLESS BUZZER
LEFT HEADLIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT SIDE BSI RADAR UNIT
LEFT TAILLIGHT/ REAR SIDE MARKER LIGHT
MILLIMETER WAVE RADAR
PANORAMIC GLASS ROOF MOTOR-CONTROL UNIT
PARKING/ BACK-UP SENSOR CONTROL UNIT
POWER DISTRIBUTION MODULE SMART FET
POWER SUNSHADE MOTOR- CONTROL UNIT
REAR WINDOW DEFOGGER
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR OUTER HANDLE
RIGHT REAR POWER WINDOW SWITCH
SRS UNIT
VSA MODULATOR CONTROL UNIT
W/ KEYLESS ACCESS
Go to component -> Ground distribution circuit (3 of 5) -> RIGHT REAR DOOR OUTER HANDLE
right rear door outer handle wiring diagram (3 of 3)
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCK KNOB
FUSE 18
FUSE 25
FUSE 39
GAUGE CONTROL MODULE
GRN WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
LOCK
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR LOCK ACTUATOR
RIGHT REAR DOOR LOCK KNOB SWITCH
RIGHT REAR DOOR OUTER HANDLE
RIGHT REAR DOOR SWITCH
SECURITY INDICATOR
TAN WIRE
THERMAL JOINT 4
TOUCH SENSOR (LOCK)
TOUCH SENSOR (UNLOCK)
UNDER- HOOD FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
UNLOCK
W/ KEYLESS ACCESS
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (4 of 6) -> RIGHT REAR DOOR OUTER HANDLE
