Acura RDX III (2018-2021) driver's seat height support motor Wiring diagram
This page shows the only wiring diagram for the component.driver's seat height support motor, which is found in the car Acura RDX III (2018-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat height support motor (1 of 1)
BLK WIRE
BRN WIRE
CAN GATEWAY
CENTER DISPLAY UNIT
DRIVER'S POWER SEAT CONTROL UNIT
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT CUSHION BLOWER MOTOR
DRIVER'S SEAT CUSHION HEATER
DRIVER'S SEAT HEIGHT MOTOR
DRIVER'S SEAT HEIGHT SUPPORT MOTOR
DRIVER'S SEAT LEFT BOLSTER MOTOR
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR A
DRIVER'S SEAT POWER LUMBAR SUPPORT MOTOR B
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT RIGHT BOLSTER MOTOR
DRIVER'S SEAT SLIDE MOTOR
DRIVER'S SEAT TILT MOTOR
DRIVER'S SEAT- BACK HEATER
DRIVER'S SEAT-BACK BLOWER MOTOR
FRONT ACCESSORY POWER SOCKET
FRONT SEAT CONTROL HEATER UNIT/ VENTILATED SEAT CONTROL UNIT
FRONT USB CHARGER UNIT
GLOVE BOX LIGHT
INFOTAINMENT CONTROL UNIT
LEFT REAR DOOR LATCH
LEFT REAR DOOR OUTER HANDLE
LEFT REAR POWER WINDOW SWITCH
LEFT REAR SEAT BACK HEATER
LEFT REAR SEAT CUSHION HEATER
REAR USB CHARGER UNIT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT SIDE BSI RADAR UNIT
RIGHT TAILLIGHT/ REAR SIDE MARKER LIGHT
STEREO AMPLIFIER
TELEMATICS CONTROL UNIT
TUNER UNIT
W/ KEYLESS ACCESS
Go to component -> Ground distribution circuit (4 of 5) -> DRIVER'S SEAT HEIGHT SUPPORT MOTOR
