Memory seat circuit for Acura RDX II (2013-2015)
Memory seat circuit (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX
DRIVER'S SEAT FRONT UP-DOWN MOTOR
DRIVER'S SEAT REAR UP-DOWN MOTOR
DRIVER'S SEAT RECLINE MOTOR
DRIVER'S SEAT SLIDE MOTOR
FUSE 3-1
FUSE 3-2
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX FUSE 5 (BEHIND LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
PNK WIRE
POWER SEAT CONTROL UNIT
PPL
PPL PPL
RED WIRE
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Memory seat circuit (2 of 2)
BACK
BLK WIRE
BLU WIRE
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
DRIVER'S POWER SEAT ADJUSTMENT SWITCH
DRIVING POSITION MEMORY SWITCH
DRIVING POSITION MEMORY SWITCH LIGHT
FRONT UP-DOWN SWITCH
FUSE 29
GRN WIRE
HOT AT ALL TIMES
J/C
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
POSITION
POSITION SET SWITCH SWITCH
POWER WINDOW MASTER SWITCH
PPL
REAR UP-DOWN SWITCH
RECLINE SWITCH
RED WIRE
SLIDE SWITCH
SWITCH
TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION)
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
UP PNK WIRE
WHT WIRE
YEL WIRE
