Entry light timer circuit for Acura RDX II (2013-2015)
Entry light timer circuit (1 of 2)
6 11 PNK PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S VANITY MIRROR LIGHT
FRONT PASSENGER'S DOOR COURTESY LIGHT
FUSE
FUSE BOX (LEFT REAR OF ENGINE COMPT)
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTERIOR LIGHT CUT RELAY
LEFT CARGO AREA LIGHT
LEFT FRONT INDIVIDUAL MAP LIGHT
LT BLU WIRE
LT GRN WIRE
MICU
OF DASH)
ORG/ WIRE
PASSENGER'S VANITY MIRROR LIGHT
PNK 6 7 WIRE
PNK WIRE
POWER TAILGATE INSIDE SWITCH
PPL
RED WIRE
RIGHT CARGO AREA LIGHT
RIGHT FRONT INDIVIDUAL MAP LIGHT
ROOF CONSOLE MODULE (CENTER FRONT OF ROOF)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE
UNDER-HOOD FUSE/RELAY
WHT WIRE
Entry light timer circuit (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CEILING LIGHT
COMPUTER DATA LINES SYSTEM
CONTROL BLOCK
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK ACTUATOR/KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR SWITCH
DRIVER'S JUNCTION BOX
FRONT PASSENGER'S DOOR SWITCH
GRN WIRE
KEY/ DOOR LOCK KNOB
KEYLESS ACCESS CONTROL UNIT
LEFT REAR DOOR SWITCH
LT GRN WIRE
ORG/ WIRE
PNK 6 7 WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
RF UNIT (BELOW CENTER CONSOLE ARMREST)
RIGHT REAR DOOR SWITCH
TRANSMITTER
WHT WIRE
YEL WIRE
