Acura RDX II (2013-2015) washer main relay Wiring diagrams
This page contains all the electrical diagrams for the component. washer main relay, in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
washer main relay wiring diagram (1 of 3)
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
ORG/ WIRE
PNK WIRE
POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER
PPL
RED WIRE
RELAY
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WASHER FLUID LEVEL SWITCH (CANADA)
WASHER MAIN RELAY
WHT WIRE
WINDSHIELD WIPER HIGH/LOW RELAY
WINDSHIELD WIPER INTERMITTENT RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER MOTOR (UNDER LEFT COWL PANEL)
WINDSHIELD/REAR WINDOW WASHER MOTOR (IN WASHER RESERVOIR)
YEL WIRE
Go to component -> Front wiper/washer circuit (2 of 2) -> WASHER MAIN RELAY
washer main relay wiring diagram (2 of 3)
A/T GEAR POSITION INDICATOR
ACURALINK CONTROL UNIT (XM RECEIVER) (W/ NAVIGATION)
ANC/ ACTIVE SOUND CONTROL UNIT
AUDIO DISPLAY UNIT
AUDIO MULTI- UNIT/ INFORMATION AUDIO- DISPLAY NAVIGATION UNIT UNIT
AUDIO NAVIGATION SWITCH PANEL
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUDIO UNIT/ AUDIO- NAVIGATION UNIT (W/O NAVIGATION)
BACKUP CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
DRIVER'S DRIVER'S SEAT SEAT HEATER HEATER RELAY RELAY (LOW) (HIGH)
DRIVER'S POWER LUMBAR SUPPORT SWITCH
FROM FUSE 23 (DIAGRAM 1 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FUSE
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 2-3
FUSE 31
GAUGE CONTROL MODULE
GRN WIRE
HOMELINK UNIT
INTERFACE DIAL
KEYLESS ACCESS CONTROL UNIT
LT BLU WIRE
MICU
MOON- ROOF CONTROL UNIT/ MOTOR
MULTI INFORMATION DISPLAY UNIT
PPL
SUNLIGHT SENSOR
TO DRIVER'S JUNCTION BOX (DIAGRAM 6 OF 6)
W/ NAVIGATION
W/O NAVIGATION
WASHER MAIN RELAY
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> WASHER MAIN RELAY
washer main relay wiring diagram (3 of 3)
A/T GEAR POSITION INDICATOR
BLK WIRE
BLU WIRE
GRN WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT)
PPL
REAR WINDOW WIPER MOTOR (CENTER OF TAILGATE)
REAR WINDOW WIPER RELAY
RED WIRE
RELAY
TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WASHER MAIN RELAY
WHT WIRE
WINDSHIELD WIPER HIGH/LOW RELAY
WINDSHIELD WIPER INTERMITTENT RELAY
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Rear wiper/washer circuit (2 of 2) -> WASHER MAIN RELAY
