Acura RDX II (2013-2015) roof console module Wiring diagram
This page shows the only wiring diagram for the component.roof console module, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram roof console module (1 of 1)
20 21 22 PPL
AUTO CLOSE
AUTO OPEN
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
COMPUTER DATA LINES SYSTEM
CONTROL BLOCK
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/ KEY CYLINDER SWITCH
DRIVER'S DOOR SWITCH
FRONT PASSENGER'S DOOR SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE
GRN WIRE
GRY WIRE
HALL SENSOR
HOT AT ALL TIMES
INPUT CIRCUIT
KEY
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
MOONROOF CONTROL UNIT/MOTOR (CENTER OF ROOF)
OPEN OFF CLOSE
ORG/ WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
REG
ROOF CONSOLE MODULE
SIDE OF DASH)
TILT SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT
UNLCK
WHT WIRE
YEL WIRE
Go to component -> Power top/sunroof circuit -> ROOF CONSOLE MODULE
