Acura RDX II (2013-2015) right rear satellite speaker Wiring diagrams
This page contains all the electrical diagrams for the component. right rear satellite speaker, in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear satellite speaker (1 of 2)
5 6 7 8 9 10 11 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR SPEAKER
FRONT CENTER SPEAKER (+)
FRONT PASSENGER'S DOOR SPEAKER
GRN WIRE
GRY WIRE
LEFT REAR DOOR SPEAKER
LEFT REAR SATELLITE SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL PPL
RED WIRE
RIGHT REAR DOOR SPEAKER
RIGHT REAR SATELLITE SPEAKER
RIGHT TWEETER
STEREO AMPLIFIER (BELOW CENTER CONSOLE)
SUBWOOFER
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (6 of 7) -> RIGHT REAR SATELLITE SPEAKER
Wiring diagram right rear satellite speaker (2 of 2)
5 6 7 8 9 10 11 PNK WIRE
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S DOOR SPEAKER
FRONT CENTER SPEAKER (+)
FRONT PASSENGER'S DOOR SPEAKER
GRN WIRE
GRY WIRE
LEFT REAR DOOR SPEAKER
LEFT REAR SATELLITE SPEAKER
LEFT TWEETER
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL PPL
RED WIRE
RIGHT REAR DOOR SPEAKER
RIGHT REAR SATELLITE SPEAKER
RIGHT TWEETER
STEREO AMPLIFIER (BELOW CENTER CONSOLE)
SUBWOOFER
WHT WIRE
YEL WIRE
Go to component -> Radio circuit, with navigation (6 of 7) -> RIGHT REAR SATELLITE SPEAKER
