Acura RDX II (2013-2015) power tailgate inside beeper Wiring diagram
This page shows the only wiring diagram for the component.power tailgate inside beeper, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power tailgate inside beeper (1 of 1)
12 13 PPL
B-CAN H
B-CAN L
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 1-5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT POWER TAILGATE PINCH SENSOR (UPPER LEFT SIDE OF TAILGATE)
LT BLU WIRE
LT GRN WIRE
MULTI-INFORMATION DISPLAY
NETWORK CONTROLLER CONTROLLER AREA POWER SUPPLY CIRCUIT/
ORG/ WIRE
PNK 10 11 WIRE
PNK WIRE
POWER TAILGATE CLUTCH
POWER TAILGATE CONTROL UNIT (LEFT SIDE OF CARGO AREA)
POWER TAILGATE DRIVE UNIT (UPPER LEFT "D" PILLAR)
POWER TAILGATE INSIDE BEEPER
POWER TAILGATE MOTOR
POWER TAILGATE OUTSIDE BEEPER (LEFT SIDE OF REAR BUMPER)
POWER TAILGATE SENSOR
PPL
PPL PPL
RED WIRE
RIGHT POWER TAILGATE PINCH SENSOR (UPPER RIGHT SIDE OF TAILGATE)
TAILGATE OUTER HANDLE SWITCH (CENTER OF TAILGATE)
TRANSCEIVER B-CAN
TRANSMISSIONS SYSTEM
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Power tailgate circuit (1 of 2) -> POWER TAILGATE INSIDE BEEPER
