Acura RDX II (2013-2015) power supply circuit/ controller area network controller Wiring diagrams

1 2 3 4 PPL AWD CONTROL UNIT (LEFT "D" PILLAR) AWD IND AWD RELAY BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 2 COMPULSORY TURNING- ON CIRCUIT COMPUTER DATA LINES SYSTEM F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE FUSE 1-2 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT REAR OF ENGINE COMPT) HOT IN ON OR START INDICATOR DRIVE CIRCUIT LT BLU WIRE LT GRN WIRE MICU MULTI-INFORMATION DISPLAY ORG/ WIRE PNK WIRE POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER PPL PRESSURE SENSOR REAR DIFFERENTIAL FLUID PRESSURE SENSOR (RIGHT SIDE OF REAR DIFFERENTIAL) REAR DIFFERENTIAL FLUID TEMPERATURE SENSOR (RIGHT SIDE OF REAR DIFFERENTIAL) REAR DIFFERENTIAL PUMP MOTOR (LEFT SIDE OF REAR DIFFERENTIAL) REAR DIFFERENTIAL SOLENOID VALVE (RIGHT SIDE OF REAR DIFFERENTIAL) RED WIRE TAN WIRE UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) WHT WIRE YEL WIRE

B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BRN WIRE CENTER JUNCTION BOX 2 COMPUTER DATA LINES SYSTEM GAUGE CONTROL MODULE GRN WIRE GRY WIRE ORG/ WIRE PNK WIRE POWER SUPPLY CIRCUIT/ CONTROLLER AREA NETWORK CONTROLLER PPL RED WIRE RELAY UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) WASHER FLUID LEVEL SWITCH (CANADA) WASHER MAIN RELAY WHT WIRE WINDSHIELD WIPER HIGH/LOW RELAY WINDSHIELD WIPER INTERMITTENT RELAY WINDSHIELD WIPER MOTOR WINDSHIELD WIPER MOTOR (UNDER LEFT COWL PANEL) WINDSHIELD/REAR WINDOW WASHER MOTOR (IN WASHER RESERVOIR) YEL WIRE
