Acura RDX II (2013-2015) park pin switch/ shift lock solenoid/ a/t gear position indicator panel light Wiring diagram
This page shows the only wiring diagram for the component.park pin switch/ shift lock solenoid/ a/t gear position indicator panel light, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram park pin switch/ shift lock solenoid/ a/t gear position indicator panel light (1 of 1)
A/T GEAR POSITION INDICATOR
ANC/ACTIVE SOUND CONTROL UNIT
AUDIO CLIMATE NAVIGATION CONTROL SWITCH PANEL UNIT
AUDIO DISPLAY UNIT
BACKUP CONTROL UNIT
BATTERY SENSOR
BLK WIRE
CABLE REEL
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CONSOLE DRIVER'S BOX SEAT HEATER LIGHT RELAY (HIGH)
CRUISE CONTROL COMBINATION SWITCH
DRIVER'S SEAT HEATER RELAY (LOW)
ELECTRIC ACCESSORY STEERING RELAY LOCK
ENGINE START/STOP SWITCH
EPS CONTROL UNIT
FRONT ACURALINK ACCESSORY CONTROL UNIT POWER (XM RECEIVER) SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S DRIVER'S SEAT HEATER SEAT HEATER SWITCH SWITCH
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
GAUGE CONTROL MODULE
GLOVE BOX LIGHT
HVAC DISPLAY UNIT
INTERFACE DIAL
KEYLESS ACCESS CONTROL UNIT
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
PARK PIN SWITCH/ SHIFT LOCK SOLENOID/ A/T GEAR POSITION INDICATOR PANEL LIGHT
POWER CONTROL UNIT
POWER ENGINE MOUNT TRANSISTOR CONTROL UNIT
REAR WINDOW WASHER WIPER MAIN RELAY RELAY
RIGHT POWER MIRROR
STEERING ANGLE SENSOR
STEERING WHEEL)
SUNLIGHT SENSOR
TORQUE SENSOR
TPMS CONTROL UNIT
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 5) -> PARK PIN SWITCH/ SHIFT LOCK SOLENOID/ A/T GEAR POSITION INDICATOR PANEL LIGHT
