Acura RDX II (2013-2015) on hook off hook Wiring diagrams

This page contains all the electrical diagrams for the component. on hook off hook, in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram on hook off hook (1 of 3)

Wiring diagram on hook off hook for Acura RDX II (2013-2015) (1 of 3)

Get access

27 28 29 30 31 32 33 PPL AUDIO REMOTE SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT (CENTER OF DASH) AUXILIARY JACK ASSEMBLY BACK TALK BLK WIRE BLU WIRE BRN WIRE CABLE REEL CENTRAL JUNCTION BOX 2 COMPUTER DATA LINES SYSTEM FUSE GPS ANTENNA (UNDER RIGHT SIDE OF REAR SHELF) GRN WIRE GRY WIRE HOT IN ON OR START HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) FUSE HOT W/ ACCESSORY RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MICU FUSE 5 MODE CH+ NCA WIRE ON HOOK OFF HOOK ORG/ WIRE PNK WIRE PPL PPL PNK WIRE RED WIRE USB PORT VOL DOWN VOL UP CH- WHT WIRE YEL WIRE

Go to component -> Navigation circuit (1 of 7) -> ON HOOK OFF HOOK

Wiring diagram on hook off hook (2 of 3)

Wiring diagram on hook off hook for Acura RDX II (2013-2015) (2 of 3)

Get access

Go to component -> Radio circuit, with navigation (1 of 7) -> ON HOOK OFF HOOK

Wiring diagram on hook off hook (3 of 3)

Wiring diagram on hook off hook for Acura RDX II (2013-2015) (3 of 3)

Get access

10 11 12 13 14 15 PNK WIRE 16 17 18 PPL AUDIO REMOTE SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT (CENTER OF DASH) AUXILIARY JACK ASSEMBLY BACK TALK BLK WIRE BLU WIRE BRN WIRE CABLE REEL CENTRAL JUNCTION BOX 2 CH- COMPUTER DATA LINES SYSTEM FUSE FUSE 29 (LEFT REAR OF ENGINE COMPT) FUSE 5 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HOT W/ ACCESSORY RELAY ENERGIZED LT BLU WIRE MICU MODE NAVIGATION SYSTEM ON HOOK OFF HOOK ORG/ WIRE PNK WIRE PPL PPL 2 3 4 5 6 7 8 9 RED WIRE UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX VOL DOWN VOL UP CH- WHT WIRE YEL WIRE

Go to component -> Radio circuit, without navigation (1 of 5) -> ON HOOK OFF HOOK

Acura RDX II (2013-2015) on hook off hook Wiring diagrams

Wiring diagram on hook off hook (1 of 3)

List of components:

Wiring diagram on hook off hook (2 of 3)

List of components:

Wiring diagram on hook off hook (3 of 3)

List of components:
