Acura RDX II (2013-2015) network controller controller area Wiring diagram
This page shows the only wiring diagram for the component.network controller controller area, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram network controller controller area (1 of 1)
3 1 2 4 PPL
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT (CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
EVAPORATOR TEMPERATURE SENSOR (BEHIND RIGHT CENTER OF DASH)
FUSE
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT IN ON OR START
HVAC POWER TRANSISTOR
IN-CAR TEMPERATURE SENSOR (LEFT CENTER OF DASH)
LT BLU WIRE
LT GRN WIRE
MICU
MODE CONTROL MOTOR (BEHIND RIGHT CENTER OF DASH)
NETWORK CONTROLLER CONTROLLER AREA
OF DASH)
ORG/ WIRE
OUTSIDE AIR TEMPERATURE SENSOR (LEFT FRONT OF ENGINE COMPT)
PASSENGER'S AIR MIX CONTROL MOTOR (BEHIND RIGHT CENTER OF DASH)
PNK 6 7 WIRE
PNK WIRE
POWER SUPPLY CIRCUIT
PPL
REAR WINDOW/ POWER MIRROR DEFOGGER IND
REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH
RECIRCULATION CONTROL MOTOR (BEHIND RIGHT CENTER OF DASH)
RED WIRE
SUNLIGHT SENSOR (UPPER CENTER OF DASH)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE
W/ NAVIGATION
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 3) -> NETWORK CONTROLLER CONTROLLER AREA
