Acura RDX II (2013-2015) maf sensor/ iat sensor Wiring diagram
This page shows the only wiring diagram for the component.maf sensor/ iat sensor, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram maf sensor/ iat sensor (1 of 1)
A/T ACURALINK GEAR CONTROL POSITION UNIT INDICATOR (XM RECEIVER) (W/ NAVIGATION)
ACTIVE CONTROL ENGINE MOUNT (ACM) CONTROL RELAY
ANC/ ACTIVE SOUND CONTROL UNIT
AWD CONTROL UNIT (IF EQUIPPED)
AWD RELAY (IF EQUIPPED)
BACKUP CONTROL UNIT
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER JUNCTION BOX 2
DIODE
DRIVER'S JUNCTION BOX
ENGINE MOUNT CONTROL UNIT
EPS CONTROL UNIT
EVAP PCM CANISTER PURGE VALVE
FROM FUSE 1-1 (DIAGRAM 1 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 6)
FUSE
FUSE 1-2
FUSE 1-4 FUSE 1-3
FUSE 1-5 FUSE 13
FUSE 1-6
FUSE 15
FUSE 16
FUSE 2
FUSE 3 FUSE 7
FUSE 4
FUSE 5
FUSE 6
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
IGNITION COIL RELAY
LT BLU WIRE
LT GRN WIRE
MAF SENSOR/ IAT SENSOR
ORG/ WIRE
PCM
PCM AWD RELAY (IF EQUIPPED)
PCM KEYLESS ACCESS CONTROL UNIT
PGM-FI MAIN RELAY 2
PGM-FI SUB- RELAY
POWER SEAT CONTROL UNIT
POWER TAILGATE CONTROL UNIT (W/ POWER TAILGATE)
PPL
RED WIRE
REVERSE MICU RELAY
SRS UNIT
TAN WIRE
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
TPMS CONTROL UNIT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VSA MODULATOR CONTROL UNIT
W/O W/ POWER POWER TAILGATE TAILGATE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> MAF SENSOR/ IAT SENSOR
