Acura RDX II (2013-2015) left pnk Wiring diagram
This page shows the only wiring diagram for the component.left pnk, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left pnk (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
DRIVING POSITION MEMORY SWITCH LIGHT
FUSE 22
GRN WIRE
GRY WIRE
HOT IN ON OR START
LEFT
LEFT PNK WIRE
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POSITION
POWER MIRROR CONTROL UNIT (LEFT FRONT DOOR)
POWER MIRROR SWITCH
PPL
PPL 12 13
RED WIRE
RIGHT
SET SWITCH
SWITCH
SWITCH 1
SWITCH 2
SWITCH 3
SWITCH DRIVING POSITION MEMORY SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (1 of 2) -> LEFT PNK WIRE
