Acura RDX II (2013-2015) hazard warning switch ppl light Wiring diagram
This page shows the only wiring diagram for the component.hazard warning switch ppl light, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hazard warning switch ppl light (1 of 1)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL ASSEMBLY)
COMPUTER DATA LINES SYSTEM
FUSE
FUSE 1 1
GRY WIRE
HAZARD WARNING SWITCH
HAZARD WARNING SWITCH PPL LIGHT
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
LEFT FRONT PARKING/ TURN SIGNAL LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT INNER
LEFT LICENSE
LEFT TAILLIGHT/ BRAKE LIGHT
LT GRN WIRE
MICU END OF DASH)
OF VEHICLE)
ORG/ WIRE
PLATE LIGHT
PNK WIRE
POWER CONTROL UNIT (RIGHT SIDE OF STEERING COLUMN)
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF ENGINE COMPT)
PPL
RED WIRE
RIGHT FRONT SIDE MARKER LIGHT
RIGHT INNER
RIGHT LICENSE
RIGHT TAILLIGHT/ BRAKE LIGHT
TAILLIGHT
TAILLIGHT RELAY
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> HAZARD WARNING SWITCH PPL LIGHT
