Acura RDX II (2013-2015) fuse 30 fuse 32 fuse 33 fuse 8 fuse 9 Wiring diagrams
This page contains all the electrical diagrams for the component. fuse 30 fuse 32 fuse 33 fuse 8 fuse 9, in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse 30 fuse 32 fuse 33 fuse 8 fuse 9 (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
D/L DR UNLOCK RELAY
D/L LOCK RELAY
D/L UNLOCK RELAY
DOOR KEY
DOOR LOCK
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR KEY CYLINDER
FUSE 15 FUSE 22
FUSE 29 FUSE 2-4 (LEFT REAR OF ENGINE COMPT)
FUSE 30 FUSE 32 FUSE 33 FUSE 8 FUSE 9
FUSE 41
FUSE 42 FUSE 44
FUSE 5
GRN WIRE
GRY WIRE
HEADLIGHTS PNK SYSTEM WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
J/C
KNOB
LEFT REAR (UPPER LEFT DOOR "D" PILLAR) LOCK KNOB SWITCH
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
LT BLU WIRE
LT GRN WIRE
MICU
ORG/ WIRE
PNK QS COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
PPL
SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (1 of 5) -> FUSE 30 FUSE 32 FUSE 33 FUSE 8 FUSE 9
Wiring diagram fuse 30 fuse 32 fuse 33 fuse 8 fuse 9 (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
D/L DR UNLOCK RELAY
D/L LOCK RELAY
D/L UNLOCK RELAY
DOOR KEY
DOOR LOCK
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH DRIVER'S DOOR KEY CYLINDER
FUSE 15 FUSE 22
FUSE 29 FUSE 2-4 (LEFT REAR OF ENGINE COMPT)
FUSE 30 FUSE 32 FUSE 33 FUSE 8 FUSE 9
FUSE 41
FUSE 42 FUSE 44
FUSE 5
GRN WIRE
GRY WIRE
HEADLIGHTS PNK SYSTEM WIRE
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
J/C
KNOB
LEFT REAR (UPPER LEFT DOOR "D" PILLAR) LOCK KNOB SWITCH
LEFT REAR DOOR LOCK ACTUATOR/KNOB SWITCH
LT BLU WIRE
LT GRN WIRE
MICU
ORG/ WIRE
PNK QS COMPUTER DATA LINES SYSTEM WIRE
PNK WIRE
PPL
SWITCH
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (1 of 5) -> FUSE 30 FUSE 32 FUSE 33 FUSE 8 FUSE 9
