Acura RDX II (2013-2015) eps motor/ eps motor angle sensor Wiring diagram
This page shows the only wiring diagram for the component.eps motor/ eps motor angle sensor, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram eps motor/ eps motor angle sensor (1 of 1)
BLK WIRE
BRN WIRE
ELECTRICAL COMPASS UNIT
EPS MOTOR/ EPS MOTOR ANGLE SENSOR
GRY WIRE
HIGH MOUNT BRAKE LIGHT
LEFT BACKUP LIGHT
LEFT FOG LIGHT
LEFT FRONT PARKING/ TURN SIGNAL LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT HEADLIGHT (HIGH)
LEFT HEADLIGHT (LOW)
LEFT INNER TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT/ BRAKE LIGHT
POWER TAILGATE CONTROL UNIT
POWER TAILGATE DRIVE UNIT
POWER TAILGATE OUTSIDE BEEPER
RADIATOR FAN MOTOR
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RIGHT BACKUP LIGHT
RIGHT INNER TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAILLIGHT/ BRAKE LIGHT
SECURITY HOOD SWITCH
STEERING GEAR BOX
TAILGATE LOCK SWITCH
Go to component -> Ground distribution circuit (3 of 5) -> EPS MOTOR/ EPS MOTOR ANGLE SENSOR
