Acura RDX II (2013-2015) engine compt) Wiring diagrams
This page contains all the electrical diagrams for the component. engine compt), in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
engine compt) wiring diagram (1 of 3)
2 3 1 PPL
BLK WIRE
BLU WIRE
BRAKE BOOSTER PRESSURE SENSOR A
BRAKE BOOSTER PRESSURE SENSOR B
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
FUSE
FUSE FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START MICU FUSE 5 (BEHIND LEFT SIDE OF DASH)
LEFT REAR WHEEL SPEED SENSOR (AT LEFT REAR WHEEL)
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK 1 2 WIRE
PNK 14 15 16 17 18 19 20 21 22 23 24 25 26 WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF
PPL
RED WIRE
RIGHT REAR WHEEL SPEED SENSOR (AT RIGHT REAR WHEEL)
UNDER-DASH FUSE/RELAY BOX
VSA CONTROL UNIT (RIGHT SIDE OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (1 of 2) -> ENGINE COMPT)
engine compt) wiring diagram (2 of 3)
A/T GEAR POSITION
AUTOMATIC DIMMING
BLK WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
DIODE
ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT IN ON OR START
INDICATOR
INSIDE MIRROR
LEFT BACKUP LIGHT
LT BLU WIRE
MICU
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF
REVERSE RELAY
RIGHT BACKUP LIGHT
TRANSMISSION RANGE SWITCH (TOP OF TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
WHT WIRE
Go to component -> Backup lamps circuit -> ENGINE COMPT)
engine compt) wiring diagram (3 of 3)
A/T GEAR POSITION INDICATOR
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH (IN BRAKE MASTER CYLINDER)
BRN WIRE
CENTER JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH
ENGINE COMPT)
FRONT PASSENGER'S DOOR SWITCH
FRONT ROCKER ARM OIL PRESSURE SWITCH
FUEL TANK UNIT (BELOW CENTER OF VEHICLE)
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LEFT REAR DOOR SWITCH
LT BLU WIRE
LT GRN WIRE
PARKING BRAKE SWITCH (PARKING BRAKE PEDAL ASSEMBLY)
POWERTRAIN CONTROL MODULE (PCM) (RIGHT SIDE OF
PPL
REAR ROCKER ARM OIL PRESSURE SWITCH
RED WIRE
RIGHT REAR DOOR SWITCH
UNDER-DASH FUSE/RELAY BOX MICU (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> ENGINE COMPT)
