Acura RDX II (2013-2015) defogger left power mirror Wiring diagram
This page shows the only wiring diagram for the component.defogger left power mirror, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram defogger left power mirror (1 of 1)
30 28 PNK WIRE
36 15 PPL
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CLIMATE CONTROL UNIT (CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DEFOGGER LEFT POWER MIRROR
DEFOGGER RIGHT POWER MIRROR
FRONT PASSENGER'S POWER WINDOW SWITCH
FUSE 2-7
FUSE 22
FUSE 44
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
PNK WIRE
POWER WINDOW MASTER SWITCH
PPL
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER IND/ POWER MIRROR DEFOGGER IND
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH/ POWER MIRROR DEFOGGER SWITCH
RED WIRE
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
W/ NAVIGATION COMPUTER DATA LINES SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit -> DEFOGGER LEFT POWER MIRROR
