Acura RDX II (2013-2015) cruise main ind Wiring diagram
This page shows the only wiring diagram for the component.cruise main ind, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cruise main ind (1 of 1)
BLK WIRE
BRAKE PEDAL POSITION SWITCH (BRAKE PEDAL ASSEMBLY)
BRN WIRE
CABLE REEL
CANCEL RESUME SWITCH SWITCH
CENTER JUNCTION BOX 2
CIRCUIT
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL COMBINATION SWITCH
CRUISE CONTROL IND
CRUISE LIGHT DIMMING CIRCUIT
CRUISE MAIN IND
DISPLAY
F-CAN
F-CANH
F-CANL
FUSE FUSE
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HORN SWITCH
HOT IN ON OR START
INDICATOR DRIVE CIRCUIT
INFO/DOWN SWITCH
INFO/UP SWITCH
LT BLU WIRE
LT GRN WIRE
MAIN SWITCH
MICU
MULTI-INFORMATION
ORG/ WIRE
PADDLE SHIFTER + (UPSHIFT SWITCH)
PNK WIRE
POWER SUPPLY CIRCUIT/CONTROLLER AREA NETWORK CONTROLLER
RED WIRE
SET SWITCH
SET/ RESET SWITCH
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (2 of 2) -> CRUISE MAIN IND
