Acura RDX II (2013-2015) computer data lines, sound systems Wiring diagram
This page shows the only wiring diagram for the component.computer data lines, sound systems, which is found in the car Acura RDX II (2013-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram computer data lines, sound systems (1 of 1)
AIR CONDITIONING SYSTEM
AIR CONDITIONING, HEADLIGHTS, EXTERIOR LIGHTS SYSTEMS
AIR CONDITIONING, INSTRUMENT CLUSTER, NAVIGATION,
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES, SOUND SYSTEMS
DOOR LOCKS SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
ENGINE CONTROLS SYSTEM CRUISE CONTROL SYSTEM
ENGINE CONTROLS SYSTEM INSTRUMENT CLUSTER SYSTEM
ENGINE CONTROLS, TRUNK, TAILGATE, FUEL DOORS, MEMORY, TRANSMISSIONS SYSTEMS
ENGINE CONTROLS, WARNING SYSTEMS
EXTERIOR LIGHTS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS
EXTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS, POWER DISTRIBUTION SYSTEMS
EXTERIOR LIGHTS, MIRRORS SYSTEMS
FUSE
FUSE FUSE
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM POWER DISTRIBUTION SYSTEM WIPER/WASHER SYSTEM
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
INSTRUMENT CLUSTER SYSTEM INSTRUMENT CLUSTER, SOUND SYSTEMS
INTERIOR LIGHTS, TRUNK, TAILGATE, FUEL DOORS SYSTEMS
LT BLU WIRE
LT GRN WIRE
MEMORY SYSTEMS
MICU
MICU UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
MIRRORS SYSTEM EXTERIOR LIGHTS SYSTEM
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM
PPL
PPL PNK PPL WIRE
RED WIRE
SOUND SYSTEMS
TRUNK, TAILGATE, FUEL DOORS SYSTEM
UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
WIPER/WASHER SYSTEM
WIPER/WASHER SYSTEM EXTERIOR LIGHTS SYSTEM
YEL WIRE
Go to component -> Body control modules circuit -> COMPUTER DATA LINES, SOUND SYSTEMS
