Acura RDX II (2013-2015) back talk Wiring diagrams
This page contains all the electrical diagrams for the component. back talk, in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
back talk wiring diagram (1 of 3)
27 28 29 30 31 32 33 PPL
AUDIO REMOTE SWITCH
AUDIO UNIT/AUDIO NAVIGATION UNIT (CENTER OF DASH)
AUXILIARY JACK ASSEMBLY
BACK TALK
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CENTRAL JUNCTION BOX 2
COMPUTER DATA LINES SYSTEM
FUSE
GPS ANTENNA (UNDER RIGHT SIDE OF REAR SHELF)
GRN WIRE
GRY WIRE
HOT IN ON OR START
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (BEHIND LEFT SIDE OF DASH) FUSE
HOT W/ ACCESSORY RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
MICU FUSE 5
MODE CH+
NCA WIRE
ON HOOK OFF HOOK
ORG/ WIRE
PNK WIRE
PPL
PPL PNK WIRE
RED WIRE
USB PORT
VOL DOWN
VOL UP CH-
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit (1 of 7) -> BACK TALK
