Acura RDX II (2013-2015) anc/ active sound control unit Wiring diagrams
This page contains all the electrical diagrams for the component. anc/ active sound control unit, in which he is found in the car Acura RDX II (2013-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram anc/ active sound control unit (1 of 2)
A/T ACURALINK GEAR CONTROL POSITION UNIT INDICATOR (XM RECEIVER) (W/ NAVIGATION)
ACTIVE CONTROL ENGINE MOUNT (ACM) CONTROL RELAY
ANC/ ACTIVE SOUND CONTROL UNIT
AWD CONTROL UNIT (IF EQUIPPED)
AWD RELAY (IF EQUIPPED)
BACKUP CONTROL UNIT
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CENTER JUNCTION BOX 2
DIODE
DRIVER'S JUNCTION BOX
ENGINE MOUNT CONTROL UNIT
EPS CONTROL UNIT
EVAP PCM CANISTER PURGE VALVE
FROM FUSE 1-1 (DIAGRAM 1 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 6)
FUSE
FUSE 1-2
FUSE 1-4 FUSE 1-3
FUSE 1-5 FUSE 13
FUSE 1-6
FUSE 15
FUSE 16
FUSE 2
FUSE 3 FUSE 7
FUSE 4
FUSE 5
FUSE 6
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
IGNITION COIL RELAY
LT BLU WIRE
LT GRN WIRE
MAF SENSOR/ IAT SENSOR
ORG/ WIRE
PCM
PCM AWD RELAY (IF EQUIPPED)
PCM KEYLESS ACCESS CONTROL UNIT
PGM-FI MAIN RELAY 2
PGM-FI SUB- RELAY
POWER SEAT CONTROL UNIT
POWER TAILGATE CONTROL UNIT (W/ POWER TAILGATE)
PPL
RED WIRE
REVERSE MICU RELAY
SRS UNIT
TAN WIRE
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 1 OF 6)
TO UNDER-HOOD FUSE/RELAY BOX (DIAGRAM 2 OF 6)
TPMS CONTROL UNIT
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
VSA MODULATOR CONTROL UNIT
W/O W/ POWER POWER TAILGATE TAILGATE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> ANC/ ACTIVE SOUND CONTROL UNIT
Wiring diagram anc/ active sound control unit (2 of 2)
A/T GEAR POSITION INDICATOR
ACURALINK CONTROL UNIT (XM RECEIVER) (W/ NAVIGATION)
ANC/ ACTIVE SOUND CONTROL UNIT
AUDIO DISPLAY UNIT
AUDIO MULTI- UNIT/ INFORMATION AUDIO- DISPLAY NAVIGATION UNIT UNIT
AUDIO NAVIGATION SWITCH PANEL
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUDIO UNIT/ AUDIO- NAVIGATION UNIT (W/O NAVIGATION)
BACKUP CONTROL UNIT
BLK WIRE
BLU WIRE
BRN WIRE
CENTER JUNCTION BOX 1
CENTER JUNCTION BOX 2
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
DRIVER'S DRIVER'S SEAT SEAT HEATER HEATER RELAY RELAY (LOW) (HIGH)
DRIVER'S POWER LUMBAR SUPPORT SWITCH
FROM FUSE 23 (DIAGRAM 1 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 1 OF 6)
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FUSE
FUSE 10
FUSE 11
FUSE 12
FUSE 13
FUSE 14
FUSE 2-3
FUSE 31
GAUGE CONTROL MODULE
GRN WIRE
HOMELINK UNIT
INTERFACE DIAL
KEYLESS ACCESS CONTROL UNIT
LT BLU WIRE
MICU
MOON- ROOF CONTROL UNIT/ MOTOR
MULTI INFORMATION DISPLAY UNIT
PPL
SUNLIGHT SENSOR
TO DRIVER'S JUNCTION BOX (DIAGRAM 6 OF 6)
W/ NAVIGATION
W/O NAVIGATION
WASHER MAIN RELAY
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> ANC/ ACTIVE SOUND CONTROL UNIT
