Car Wiring Diagrams for Heated seats circuit for Acura RDX I facelift (2009-2012)

BLK WIRE BLU WIRE DRIVER'S SEAT CUSHION HEATER DRIVER'S SEAT HEATER DRIVER'S SEAT HEATER RELAY (HIGH) (UNDER LEFT SIDE OF DASH) DRIVER'S SEAT HEATER RELAY (LOW) (UNDER LEFT SIDE OF DASH) DRIVER'S SEAT HEATER SWITCH DRIVER'S SEAT- BACK HEATER FRONT PASSENGER'S SEAT CUSHION HEATER FRONT PASSENGER'S SEAT HEATER FRONT PASSENGER'S SEAT HEATER RELAY (HIGH) FRONT PASSENGER'S SEAT HEATER RELAY (LOW) FRONT PASSENGER'S SEAT HEATER SWITCH FUSE 36 FUSE 5 GRN WIRE GRY WIRE HIGH INDICATOR HOT AT ALL TIMES HOT IN ON ILLUMINATION SWITCH LOW INDICATOR LT GRN WIRE MICU HAC ORG/ WIRE PNK WIRE PPL RED WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) YEL WIRE
