Car Wiring Diagrams for Immobilizer circuit for Acura RDX I facelift (2009-2012)

+B BACKUP +B BACKUP PUMP BLK WIRE BLK/YEL WIRE BLU WIRE BODY CONTROLLER AREA NETWORK TRANSCEIVER BRN WIRE BRN/YEL WIRE BUS - COMPUTER DATA LINES SYSTEM CONTROLLER AREA DRIVER'S CIRCUIT IMMOBILIZER SYSTEM INDICATOR ENGINE CONTROLS SYSTEM FPCD FPC FP+ FP- GND FUEL FUEL PUMP FUEL PUMP CONTROL MODULE (LEFT "C" PILLAR) FUEL TANK UNIT (IN TOP OF FUEL TANK) FUSE 19 FUSE 23 FUSE 2 GAUGE CONTROL MODULE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY SWITCH IGNITION KEY SWITCH/ KEY LIGHT IMMOBILIZER KEYLESS CONTROL UNIT (ON STEERING COLUMN COVER) J/C K LINE KEY IN IGNITION KEY S-NET SW B-CAN SCS LT BLU WIRE LT GRN WIRE MICU NETWORK CONTROLLER ORG/ WIRE PARKING BRAKE CHECK CIRCUIT PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER) PCM (LEFT FRONT OF ENGINE COMPT) PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 PNK B-CAN WIRE PNK KEY SW WIRE PNK PNK WIRE PNK WIRE POWER DISTRIBUTION SYSTEM S-NET UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT) VBU WHT WIRE YEL WIRE
