Acura RDX I facelift (2009-2012) telm sig + hft mute t/c rx- t/c tx- remote gnd amp mute Wiring diagram

AMP MUTE AUDIO SWITCH PANEL AUDIO UNIT AUDIO-SI BLK WIRE BLU WIRE BRN WIRE CLIMATE CONTROL UNIT (BEHIND GLOVE BOX) DRIVER'S DOOR SPEAKER ENCODER ENCODER - PNL DATA 2 PNL CE PNL SH 1 FL PRE- FL SP+ FL TW SP - FR PRE- FR SP+ FR TW SP + FRONT PASSENGER'S DOOR SPEAKER GRN WIRE GRY WIRE HANDSFREELINK CONTROL UNIT (UNDER CENTER CONSOLE) HFT ICON HFT MUTE ILL LCD BL + LCD CE LCD CLK LCD DATA 1 LCD RST LCD SH LEFT REAR DOOR SPEAKER LEFT TWEETER LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM ORG/ WIRE PNK WIRE PNL CE PNL CLK PNL DATA 1 PNL DATA 2 PNL RST PNL SH 1 PNL SH 2 PPL PTT RED WIRE RIGHT REAR DOOR SPEAKER RIGHT TWEETER RL PRE- RL SP+ RR PRE- RR SP- SH FL GND SH FR GND SH RL GND SH RR GND SH SUBW GND STEREO AMPLIFIER (UNDER MIDDLE OF DASH) SUBW PRE- SUBW SP - SUBWOOFER SUPPLEMENTAL RESTRAINTS SYSTEM SWD +B SWD +B FL PRE + SH FR GND FR PRE + RL PRE + SH RR GND RR PRE + SUBW PRE + T/C RX+ T/C TX+ REMOTE TELM SIG + HFT MUTE T/C RX- T/C TX- REMOTE GND AMP MUTE TELM SIG - TELM SIG SH WHT WIRE YEL WIRE
