Acura RDX I facelift (2009-2012) front passenger's vanity mirror roof light console Wiring diagram
This page shows the only wiring diagram for the component.front passenger's vanity mirror roof light console, which is found in the car Acura RDX I facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's vanity mirror roof light console (1 of 1)
AUTOMATIC DIMMING INSIDE MIRROR
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH
BRN WIRE
DEFOGGER
DLC
DRIVER'S POWER POWER WINDOW WINDOW MASTER MOTOR SWITCH SWITCH
DRIVER'S VANITY MIRROR MOONROOF LIGHT SWITCH
ELD UNIT
ELECTRIC VACUUM PUMP
EXCEPT TECHNOLOGY PACKAGE TECHNOLOGY PACKAGE
FAN CONTROL RELAY
FRONT PASSENGER'S VANITY MIRROR ROOF LIGHT CONSOLE
FUEL PUMP
GRY WIRE
KEYLESS BUZZER
LEFT POWER MIRROR
LEFT SIDE TURN SIGNAL LIGHT
MICU
MICU SERVICE CHECK CONNECTOR
MOONROOF CONTROL UNIT
POWER GAUGE CONTROL MIRROR MODULE SWITCH
POWER MIRROR MEMORY CONTROL UNIT
POWER WINDOW MASTER SWITCH
PSP SWITCH
REARVIEW MONITOR MIRROR
RIGHT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT HEADLIGHT
SH-AWD CONTROL RELAY MODULE
SH-AWD CONTROL UNIT
VSA MODULATOR CONTROL UNIT
VSA OFF SWITCH
WHT WIRE
WINDSHIELD SECURITY WIPER HOOD MOTOR SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> FRONT PASSENGER'S VANITY MIRROR ROOF LIGHT CONSOLE
