Acura RDX I facelift (2009-2012) a/t gear position indicator tpms panel light/ control park pin switch unit Wiring diagram
This page shows the only wiring diagram for the component.a/t gear position indicator tpms panel light/ control park pin switch unit, which is found in the car Acura RDX I facelift (2009-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/t gear position indicator tpms panel light/ control park pin switch unit (1 of 1)
A/T GEAR POSITION INDICATOR TPMS PANEL LIGHT/ CONTROL PARK PIN SWITCH UNIT
AUDIO UNIT
AUDIO-HVAC SUB-DISPLAY UNIT
BLK WIRE
CABLE REEL
CLIMATE CONTROL UNIT
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CONSOLE BOX LIGHT
CRUISE CONTROL COMBINATION SWITCH
DRIVER'S CLIMATE CONTROL PANEL SWITCH
DRIVER'S SEAT HEATER RELAY (HIGH)
DRIVER'S SEAT HEATER RELAY (LOW)
DRIVER'S SEAT HEATER SWITCH
EXCEPT TECHNOLOGY PACKAGE
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT HEATER RELAY (HIGH)
FRONT PASSENGER'S SEAT HEATER RELAY (LOW)
FRONT PASSENGER'S SEAT HEATER SWITCH
GLOVE BOX LIGHT
GRN WIRE
GRY WIRE
HANDS
IGNITION KEY SWITCH/KEY LIGHT
NAVIGATION DISPLAY UNIT
NAVIGATION INTERFACE SWITCH DIAL PANEL
RIGHT POWER MIRROR DEFOGGER
STEERING ANGLE SENSOR
STEERING WHEEL)
STEREO AMPLIFIER
TECHNOLOGY PACKAGE
YAW RATE-LATERAL ACCELERATION SENSOR
Go to component -> Ground distribution circuit (3 of 4) -> A/T GEAR POSITION INDICATOR TPMS PANEL LIGHT/ CONTROL PARK PIN SWITCH UNIT
