Tire pressure monitoring circuit for Acura RDX I (2006-2009)

+B BACK UP +B TPMS METER METER METER AREA NETWORK CONTROLLER AREA) B-CAN L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM CONTROLLER DRIVE CIRCUIT FAST FUSE GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INI GND RL INI SIG RR INI SIG PNK WIRE LEFT FRONT RIGHT REAR TPMS INITIATOR TPMS INITIATOR (BEHIND LEFT FRONT FENDER) LEFT REAR TPMS INITIATOR (LEFT REAR WHEELWELL) LF INI + LOW TIRE PRESSURE IND LT BLU WIRE NETWORK ORG/ WIRE PNK WIRE POWER RED WIRE RIGHT FRONT TPMS INITIATOR (BEHIND LEFT FRONT FENDER) SUPPLY TPMS CONTROL UNIT (UNDER LEFT SIDE OF DASH) TPMS IND TRANSCEIVER/ UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) MICU UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH) UNDER-HOOD FUSE/RELAY FUSE BOX (LEFT REAR OF ENGINE COMPT) WARNING WHT WIRE
