Backup lamps circuit for Acura RDX I (2006-2009)
Backup lamps circuit
A/T REVERSE RELAY
AUTOMATIC DIMMING INSIDE MIRROR (ACCESSORY INSTALLED)
BLK WIRE
FUSE 10
HOT IN ON OR START
HOUSING)
LEFT BACK-UP LIGHT
LT BLU WIRE
MICU
NAVIGATION UNIT (TECHNOLOGY PACKAGE) (UNDER MIDDLE OF DASH)
PPL
RIGHT BACK-UP LIGHT
TRANSMISSION RANGE SWITCH (ON TRANSMISSION)
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL/RED WIRE
