Acura RDX I (2006-2009) wiper wiper Wiring diagram
This page shows the only wiring diagram for the component.wiper wiper, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper wiper (1 of 1)
BLK WIRE
BLU WIRE
COMBI GND (WIPER)
FUSE 10
FUSE 38
FUSE 8
GRN WIRE
HOT IN ON OR START
METER
MICU
OFF RR WIPE RR WASH RR WASH
ORG/ WIRE
PNK PPL WIRE
PNK WIRE
PPL
REAR WINDOW
REAR WINDOW WIPER MOTOR (MIDDLE OF TAILGATE)
REAR WINDOW WIPER RELAY ENGINE COMPT)
RED WIRE
RR RR WASHER WASHER WIPER SW MTR MTR
RR WASHER SW
RR WIPER WIPER AS RLY CL
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF
WINDSHIELD/ REAR WINDOW WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
WIPER WIPER
WIPER/ WASHER SWITCH
WIPER/WASHER SWITCH
Go to component -> Rear wiper/washer circuit -> WIPER WIPER
