Acura RDX I (2006-2009) wiper fr fr wiper wiper hi, lo mist sw sw Wiring diagram
This page shows the only wiring diagram for the component.wiper fr fr wiper wiper hi, lo mist sw sw, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wiper fr fr wiper wiper hi, lo mist sw sw (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMBI GND (WIPER)
CONTROLLER AREA NETWORK CONTROLLER
FR FR FR FR WIPER WIPER WIPER (AS) (HI)
FR WASHER SW
FR WIPER (INT VOL+)
FUSE 10
FUSE 38
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT IN ON OR START
INT OFF LO HI MIST
INTERMITTENT DWELL TIME CONTROLLER
METER FR WIPER RR INT, WASHER WASHER LO SW (LOW) MTR MTR METER
MICU
MIST
ORG/ WIRE
PNK WIRE
RED WIRE
UNDER-DASH FUSE/RELAY BOX
WARNING DRIVER CIRCUIT
WASHER FLUID LEVEL SWITCH (CANADA)
WHT WIRE
WINDSHIELD INT LO OFF WIPER SWITCH HI
WINDSHIELD WASHER SWITCH
WINDSHIELD WIPER MOTOR (UNDER LEFT SIDE OF COWL COVER)
WINDSHIELD/ REAR WINDOW WASHER MOTOR (BEHIND RIGHT SIDE OF FRONT BUMPER)
WIPER
WIPER FR FR WIPER WIPER HI, LO MIST SW SW
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Front wiper/washer circuit -> WIPER FR FR WIPER WIPER HI, LO MIST SW SW
