Acura RDX I (2006-2009) windshield wiper security hood switch Wiring diagram
This page shows the only wiring diagram for the component.windshield wiper security hood switch, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield wiper security hood switch (1 of 1)
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH
BRN WIRE
DEFOGGER
DLC
DRIVER'S VANITY MIRROR LIGHT
ELD UNIT
ELECTRIC VACUUM PUMP
FAN CONTROL RELAY
FRONT PASSENGER'S VANITY
FUEL PUMP CONTROL MODULE
GAUGE CONTROL MODULE
GRY WIRE
KEYLESS BUZZER
LEFT POWER MIRROR
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH
LEFT REAR POWER WINDOW SWITCH
LEFT SIDE TURN SIGNAL LIGHT
MICU
MICU SERVICE CHECK CONNECTOR
MIRROR LIGHT
MOONROOF CONTROL UNIT ROOF CONSOLE
MOONROOF SWITCH
MOTOR
POWER MIRROR MEMORY CONTROL UNIT
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
PSP SWITCH
RIGHT FOG LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL/ PARKING LIGHT
RIGHT HEADLIGHT
SH-AWD CONTROL UNIT
SH-AWD RELAY
SWITCH
VSA MODULATOR CONTROL UNIT
VSA OFF SWITCH
WHT WIRE
WINDSHIELD WIPER SECURITY HOOD SWITCH
Go to component -> Ground distribution circuit (2 of 4) -> WINDSHIELD WIPER SECURITY HOOD SWITCH
