Acura RDX I (2006-2009) trailer light in-line fuse 1 Wiring diagram
This page shows the only wiring diagram for the component.trailer light in-line fuse 1, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer light in-line fuse 1 (1 of 1)
6 5 PPL
BLK WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
END OF DASH)
FUSE 10
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
LEFT
LEFT POWER MIRROR
LEFT REAR TURN
LEFT SIDE TURN SIGNAL LIGHT
LT GRN WIRE
METER
MICU
OF ENGINE COMPT)
OFF
ORG/ WIRE
PARK
PPL
PPL 1 2 3 4 5 6 7 8 9 10 11 12
RED WIRE
RIGHT
RIGHT LEFT TURN TURN SIGNAL SIGNAL IND IND
RIGHT POWER MIRROR
RIGHT REAR TURN
RIGHT SIDE TURN SIGNAL LIGHT
SIGNAL LIGHT)
SMALL LT SW H/L ON SW H/L OFF SW COMBI GND (LIGHT) TURN LEFT SW
TRAILER HITCH CONNECTOR (ACCESSORY INSTALLED)
TRAILER LIGHT IN-LINE FUSE 1
TRAILER LIGHT IN-LINE FUSE 2
TRAILER LIGHTING CONTROL UNIT (ACCESSORY INSTALLED)
TURN RIGHT SW
TURN SIGNAL SWITCH
TURN SIGNAL/HAZARD FLASHER CIRCUIT
TURN SIGNAL/HAZARD RELAY 2 (SOUNDER) AREA NETWORK CONTROLLER
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> TRAILER LIGHT IN-LINE FUSE 1
