Acura RDX I (2006-2009) tailgate latch switch (middle of Wiring diagram
This page shows the only wiring diagram for the component.tailgate latch switch (middle of, which is found in the car Acura RDX I (2006-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate latch switch (middle of (1 of 1)
2 1 3 ON
AMBIENT LIGHTS MICROPHONE
BLK WIRE
BLU WIRE
BRN WIRE
CARGO AREA LIGHT
CEILING LIGHT
COURTESY AS
COURTESY DR
DOOR OFF
DRIVER'S DOOR COURTESY LIGHT
DRIVER'S DOOR SWITCH (LEFT "B" PILLAR)
DRIVER'S VANITY MIRROR LIGHT
FR DOOR SW (AS) RR DOOR SW (AS)
FR DOOR SW (DR) RR DOOR SW (DR)
FRONT INDIVIDUAL MAP LIGHTS RIGHT
FRONT PASSENGER'S DOOR COURTESY LIGHT
FRONT PASSENGER'S DOOR SWITCH (RIGHT "B" PILLAR)
FRONT PASSENGER'S VANITY MIRROR LIGHT
FUSE 22
GRN WIRE
GRY WIRE
HOME LINK LIGHTS
HOT AT ALL TIMES
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT SWITCH
INTR LT- TRUNK SW
LEFT
LEFT REAR DOOR SWITCH (LEFT "C" PILLAR)
LT BLU WIRE
LT GRN WIRE
MOONROOF LIGHT
NAVIGATION SYSTEM
OFF ON OFF AUTO AUTO
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT REAR DOOR SWITCH (RIGHT "C" PILLAR)
ROOF CONSOLE
TAILGATE LATCH SWITCH (MIDDLE OF
TAILGATE)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
UNDER-DASH FUSE/RELAY BOX MICU
UNDER-DASH JUNCTION BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit -> TAILGATE LATCH SWITCH (MIDDLE OF
